A surface mounted two position box with two Cat 6A jacks connects to two Cat 6A patch cords and is supported at the ceiling grid by a T-bar support adapter clip. Two Cat 6A cables run upward from the box to a structural J-hook suspended below the roof deck. A typical cable coil provides slack storage for the cabling route.
T-BAR MOUNT SURFACE MOUNTED 2 POSITION BOX WITH 2 CAT 6A JACKS, TYP. (2) CAT 6A PATCH CORDS, TYP. J-HOOK, TYP (2) CAT 6A CABLES, TYP. GRID CEILING T-BAR SUPPORT ADAPTER CLIP TO MOUNT DEVICE TO T-BAR SUPPORT CABLE COIL, TYP. ROOF/DECK
