A bare copper cable acts as the grounding electrode conductor, exothermically welded to reinforcing bars within the footing at each end. A grounding conductor runs from the footing through a PVC conduit up into a housekeeping pad, connecting to the ground bus bar inside the main service board located above. The footing and wall are constructed per structural plans, positioned below finished grade.
FINISHED GRADE REBAR PER STRUCTURAL GROUNDING ELECTRODE CONDUCTOR 40'-#4/0 BARE COPPER CABLE CADWELD TO REBAR AT EACH END FOOTING PER STRUCTURAL 1#3/0 GROUNDING CONDUCTOR IN PVC CONDUIT HOUSE KEEPING PAD WALL PER PLANS MAIN SERVICE BOARD PER PLANS GROUND BUS BAR IN MAIN BOARD
