A cast malleable iron spacer and a one-hole strap secure conduit or piping against a concrete surface. An approved fastener anchors the assembly, rated for seismic loading per delegated design.
CAST MALLEABLE IRON SPACER AND ONE HOLE STRAP -4 FASTENER APPROVED FOR SEISMIC LOADING, PER DELEGATED DESIGN
