A standard telecommunications faceplate houses Cat 6A RJ-45 data inserts and blank inserts in a white finish. A designated station number label is positioned at the top of the faceplate for circuit identification. The configuration accommodates dual data connections with typical blank inserts for future expansion.
CAT 6A, RJ-45 INSERT, WHITE, TYP BLANK INSERT, WHITE, TYP LABEL, STATION NUMBER (EXAMPLE ONLY) FACE PLATE 01 02 101-102-1
