An operable louver assembly interfaces with a 6-inch by 2-inch hollow structural section steel tube via a steel anchor bracket. The assembly features an actuator connected by a stainless steel tension hangar cable, with louvers shown in both open and closed positions. A face cap is secured at the mullion joint, and fourteen gauge stainless steel bird wire with swaged ends is provided in the horizontal direction only. A secondary steel transom is incorporated typically, with a designated wiring location noted at the top of the assembly.
FACE CAP HSS TUBE 6"X2" STEEL ANCHOR BRACKET OPERABLE LOUVER OPEN POSITION OPERABLE LOUVER CLOSED POSITION WIRING LOCATION STAINLESS STEEL 'BIRD WIRE' 14 GA. WITH SWAGED ENDS HORIZONTAL DIRECTION ONLY ACTUATOR SS TENSION HANGAR CBL. SECONDARY STEEL TRANSOM, TYP
