Wiring diagram detailing the key switch override located inside the emergency power off cabinet within the uninterruptible power supply room. The switch connects to the pre-action system panel with associated circuit routing indicators marked 5.S01 through 5.S08.
5.S01 5.S02 5.S03 5.S04 5.S05 5.S06 5.S07 5.S08 KEY SWITCH OVERRIDE IN EPO CABINET TO PRE-ACTION SYSTEM PANEL EPO CABINET IN UPS ROOM
