Generator Identification Nameplates

About this detail

This drawing outlines the fabrication and installation standards for generator identification nameplates utilizing orange Gravopoly #17047 with bold style text. Nameplates require a minimum height of three and three-eighths inches and a variable width of five inches minimum. Text specifies system feeds, voltage characteristics such as 480/277V, 3PH, 4W, and capacity ratings like 2750kW. Fastening methods require rivets on division 16 provided items in exterior locations, and double-stick tape without drilled holes on owner-furnished and interior equipment. Additional notes reference AWS equipment and labeling standards for nameplate colors and mandate nameplates on enclosures or junction boxes larger than four inches.
