Hold Down Cleat

Materials

Steel Stainless Steel

Elements

Walls Doors Connections / Plates

Connections

Base Plate / Anchorage Bolted Connection

About this detail

A precast concrete utility vault features a top section weighing 3,650 pounds and a base section weighing 8,081 pounds, measuring 9 feet 4 inches long by 4 feet 6 inches wide and 5 feet 8 inches deep. The vault includes fourteen 4.5-inch-diameter Term-A-Ducts, eight 5.57-inch-diameter Term-A-Ducts, two 2.38-inch-diameter Term-A-Ducts, one 3.51-inch-diameter Term-A-Duct, four galvanized pull irons at each corner, four 0.5-inch-diameter ground inserts, a 12-inch-diameter high-density polyethylene sump, and a 16x60-inch blockout with number 25P galvanized diamond plate doors featuring locking bolts and full 180-degree opening capability. The vault walls are reinforced with two 2-foot-long galvanized C-channels and two 5-foot-8-inch-long galvanized C-channels. Detail 1 includes the stainless steel hold down cleat secured with a stainless steel bolt and a stainless steel Belleville washer, utilizing two 0.375-inch-diameter inserts with hold down cleats required per assembly.
