Floor box type F2 includes multiple gangs for convenience receptacles and data connections, fed by underground conduits routing to the nearest stud wall. Gangs one and two provide convenience power on circuit number one, while gangs three and four accommodate data services referencing telecom drawings for exact quantities. One-inch conduits run underground to the new stud wall with pull strings terminating above the nearest accessible ceiling.
CONVENIENCE 1" CONDUIT UNDERGROUND TO NEW STUD WALL. PROVIDE PULL STRING AND TERMINATE ABOVE NEAREST ACCESSIBLE CEILING. GANG #3 GANG #4 1" CONDUIT UNDERGROUND TO NEW STUD WALL. REFER TO T-SERIES DRAWINGS FOR ADDITIONAL INFORMATION 1" CONDUIT UNDERGROUND TO NEW STUD WALL. REFER TO E-SERIES DRAWINGS FOR CIRCUITING INFORMATION (CIRCUIT #1) GANG #2 (CIRCUIT #1) GANG #1 CONVENIENCE CONVENIENCE CONVENIENCE REFER TO T-SERIES DRAWINGS FOR EXACT DATA QUANTITIES FLOOR BOX TYPE F2 REFER TO SCHEDULE ON SHEET E6.002
