Electrical · E-GXPQ2

1/1-2" Deep Electrical Box. The Terminals

Materials

Elements

About this detail

EST SIGA series modules including SIGA-CT1, SIGA-CT2, SIGA-CR, SIGA-MM1, and SIGA-WTM mount to a standard single gang, 1-1/2-inch deep compatible electrical box. The module terminals accept 14 American Wire Gauge wire. A single gang white wall plate secures over the assembly with fasteners.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
