A generator vibration isolation assembly is installed at four typical locations on a reinforced concrete pad. The generator is secured using 1/2-inch anchor bolts with a 3-1/2-inch embedment depth at each location. The concrete pad is reinforced with #6 rebar placed each way at a maximum spacing of 12 inches. An exhaust connection is positioned at the top of the generator unit.
GENERATOR VIBRATION ISOLATION ASSEMBLY (TYP. FOUR LOCATIONS) 1/2" ANCHOR BOLT 3-1/2" EMBEDMENT (TYP FOUR LOCATIONS) EXHAUST #6 REBAR EACHWAY 12" MAX. SPACING
