A medium voltage duct bank penetrates a rated wall assembly. The penetration utilizes a two-piece adjustable galvanized sheet metal sleeve attached with base plates to metal stud blocks. Mineral fiber packing fills the annular space, sealed typically with sealant on both sides. An escutcheon trim conceals the base plate corners and plate edges as required.
RATED WALL ATTACHED SLEEVE BASE PLATE TO METAL STUD BLOCKS. ESCUTCHEON TRIM BASE PLATE CORNERS AS REQUIRED TO CONCEAL PLATE BEHIND ESCUTCHEON SEALANT (TYP) MINERAL FIBER 2 PC. ADJ. GALV. SHT. METAL SLEEVE 1/2" TYP. (1/4" MIN. - 1" MAX.) N.T.S E02-05 MV DUCT BANK DETAIL 1
