Electrical and control connections for the Cake Pump 3 system located at the second floor Area F. Circuits connect maintenance box PNL-73191 to control panel PNL-73189, discharge rupture disc burst indicator ZSH-73219, hopper level high high switch LSHH-73003, and the auto-greaser. Component identification and routing are provided for power and signal lines.
CAKE PUMP 3 MAINTENANCE BOX (PNL-73191) ONE-LINE DIAGRAM SCB 2ND FLOOR - AREA F AUTO-GREASER CAKE PUMP 3 HOPPER LEVEL HIGH HIGH LSHH-73003 co r- CAKE PUMP 3 DISCHARGE RUPTURE DISC BURST INDICATOR ZSH-73219 co N CAKE PUMP 3 CONTROL PANEL PNL-73189
