An input feed from a distribution panel supplies power to a Lutron Hi-Lume LED driver operating at 120V or 277V. The driver serves digitally addressable loads with one unit per EcoSystem fixture. An EcoSystem digital loop connects the driver to EcoSystem ballasts and modules, with a maximum of 64 devices per loop, and interfaces with EcoSystem ESN units.
LUTRON LED DRIVER 120V/277V TO ECOSYSTEM BALLASTS/MODULES (64 MAX PER LOOP) HI-LUME LED ® INPUT FEED FROM DISTRIBUTION PANEL ECOSYSTEM DIGITAL LOOP # TYPICAL LED DRIVER - AS REQUIRED FOR DIGITALLY ADDRESSABLE LOADS (1) PER ECOSYSTEM FIXTURE TO ECOSYSTEM ESN TO ECOSYSTEM ESN
