Electrical · E-FYD9S

Linear Light Fixture Suspension and Seismic Bracing Detail

Elements

Connections

About this detail

A continuous linear light fixture is suspended from the structural ceiling using mounting cables and power cords provided by the manufacturer. Number 12 gauge splay wires are installed at forty-five-degree angles on both sides to limit fixture swing in the longitudinal direction. A Unicross system locks the cable, power cord, and seismic sway cable together at the fixture connection point. Splay supports are spaced at a maximum of eight feet on center, with the fixture limited to a maximum weight of five pounds per linear foot. Individual fixture segments connect as a single continuous housing using hardware and fasteners supplied by the manufacturer.
