A starter and/or disconnect switch is mounted onto Unistrut P-3000 framing standing three feet six inches high from the floor level. Incoming power feeds into the enclosure, which connects to the equipment via liquid-tight flexible conduit with a maximum length of twenty-four inches. The Unistrut vertical channels are securely anchored to the floor using floor plates at each base.
3' - 6" 1. STARTER AND/OR DISCONNECT SWITCH. 2. LIQUID TIGHT FLEX CONDUIT TO EQUIPMENT. MAX LENGTH 24". 3. UNISTRUT SECURELY ANCHORED WITH FLOOR PLATES (TYP). NOTES: 1 UNISTRUT P-3000 2 INCOMING POWER 3 NONE 1 ELEVATOR RISER DETAIL - HYDRAULIC NONE 2 FREE STANDING DISCONNECT SWITCH oQ l \ O
