An exhaust fan connects to a 480V power source through a motor starter unit designated as 78-FVNR-544-01. The control circuit includes yellow ON and OFF indicator lights along with a yellow fail indicator light. A separate local control station designated as 78-FP-544-01 provides hand-off-auto or local-remote selector switches and a reset function.
HS 78-544-011 LR HS 78-544-012 ST HS 78-544-013 SP HS 78-544-014 RESET )915 480V )3 EF EXHAUST FAN SE020NSWPMCC03-1 SE020FP900 YL 78-544-012 OFF YA FAIL YL 78-544-011 ON
