Control wiring and battery charger connections follow manufacturer specifications for a one hundred thirty kilowatt, 480Y/277-volt, three-phase, four-wire natural gas powered emergency generator set housed in a NEMA 3R enclosure. The system includes a 225-ampere, three-pole circuit breaker and designated generator connections.
CONTROL WIRING & BATTERY CHARGER CONNECTIONS PER MANUFACTURER. 130 KW, 480Y/277V-3Ø-4W NATURAL GAS POWERED EMERGENCY GENERATOR SET IN NEMA 3R ENCLOSURE. 225A 3P
