The emergency station connects via conduit containing two number fourteen conductors to a 120VAC to 24VDC transformer and an audible signal with indicating light. The system utilizes a Dukane 9A-1405A pullchain type station for dry locations or a Dukane 9A-1410B push pad type for wet locations. Power is supplied to the transformer through three number twelve conductors in a one-half inch conduit connected to the nearest 120V receptacle circuit. The audible signal uses Dukane model 43T-G6-24 and the indicating light uses Dukane model 18A-211.
CONNECT TO NEAREST 120V RECEPTACLE CIRCUIT 3#12,1/2"C AUDIBLE SIGNAL- DUKANE #43T-G6-24 INDICATING LIGHT- DUKANE # 18A-211 2#14, 1/2"C. 120VAC TO 24VDC TRANSFORMER DUKANE #PS-2420 EMERGENCY STATION DUKANE # 9A-1405A- DRY LOCATION (PULLCHAIN TYPE) 0R DUKANE # 9A-1410B- WET LOCATION (PUSH PAD TYPE) T B S
