A wet scrubber seal tank connects to twelve-inch scrubber water piping on its upper inlet and eight-inch scrubber water piping on its discharge line. The installation is supported within an industrial plant mechanical space.
12" SW WET SCRUBBER SEAL TANK r A \ I * I •- • . . I. 8" SW ■ ■ ] 8" SW D -11 -105 PHOTO B NO SCALE
