An electrical schematic diagram details the panelboard and switchboard connections within the headhouse electrical room, including distribution panels EDP2112LM, EDP2045HM, TNF2050LM, EDP2046HT, and EDP2048LP. Grounding and neutral conductors connect the equipment enclosures, alongside grounding electrode conductor (GEC) routing. Numbered tags indicate specific connection points and circuit configurations throughout the layout.
N G 1 2 EDP2048LP TNF2050LM N G 1 2 EDP2112LM EDP2045HM N G 1 2 G N G 1 2 EDP2046HT GEC G G G 5 4
