An eight-inch diameter bollard fixture with an integral access panel mounts onto a base plate equipped with four leveling pads. Four anchor bolts secure the mounting plate to a twelve-inch diameter minimum concrete foundation base. The entire assembly sits flush with the finished grade within a planter area.
8" DIAMETER BOLLARD FIXTURE ACCESS PANEL BASE MOUNTING PLATE WITH (4) LEVELING PADS FINISHED GRADE (PLANTER) (4) ANCHOR BOLTS PER MANUFACTURER CONCRETE BASE, 12" DIAMETER MINIMUM 12" MIN.
