Lighting control schematic for large rooms incorporating daylit zones and interior zones connected to room controllers, photo sensors, and occupancy sensors. Power is supplied by a 20A/1P 277V lighting panel and a 20A/1P 120V panel serving controlled receptacles and room controllers.
S S S S D OS OS D PS PS D OS OS D PS PS 20A/1P 277V 20A/1P 120V H PANEL LARGE ROOM LIGHT FIXTURE CONTROLLED RECEPTACLE ROOM CONTROLLER INTERIOR ZONE DAYLIT ZONE INTERIOR ZONE L PANEL
