A rigid galvanized steel conduit sleeve is cast into a cast-in-place concrete floor with a half-inch space all around. Two-thousand-degree Fahrenheit rated ceramic wool is packed all around the annular space, finished with a three-quarter-inch deep gun-applied sealant at the top. A pipe clamp rests on top of the concrete floor where vertical support of the raceway is required.
PIPE CLAMP REST ON TOP OF CONCRETE FLOOR WHERE VERTICAL SUPPORT OF RACEWAY IS REQUIRED. 2000°F RATED CERAMIC WOOL PACKED IN PLACE ALL AROUND. CAST IN PLACE CONCRETE FLOOR. RACEWAY RIGID GALVANIZED STEEL CONDUIT SLEEVE CAST IN PLACE IN CONCRETE 1/2" SPACE ALL AROUND 3/4" DEEP GUN APPLIED SEALANT. 2"
