Electrical one-line diagram for motor control center MCC73T2 identifying connected equipment including brine pump P-71228, SCB purge air compressor AC-71192, and associated control tags TSH-71192 and MSH-71228.
MCC73T2 ONE-LINE DIAGRAM NO SCALE TSH-71192 MSH-71192 "SCB PURGE AIR COMPRESSOR 2 AC-71192 MSH-71228 "BRINE PUMP 2 P-71228"
