The main door access network controller connects to power outlets and network lines with the exact location coordinated with the owner. A color card printer plugs into a standard receptacle alongside the controller equipment. Field verification of exact equipment locations is required.
MAIN DOOR ACCESS NETWORK CONTROLLER "ANC" COLOR CARD PRINTER COORDINATE EXACT LOCATION WITH OWNER
