E-DPJSM — Swbdlva

Electrical · E-DPJSM

Swbdlva

About this detail

The low voltage switchboard assembly is rated at 3000 amperes, 480 volts, 3-phase, 4-wire with a 100kAIC 100% rating and is fed from XXXX-TXA. The associated notes indicate that this configuration is typical for each section of switchboard, panelboards, and similar electrical equipment.

SwbdLVA 3000A, 480V, 3PH, 4W 100kAIC 100% RATED 4" 2 " FED FROM "XXXX"-TXA A. NOTES: TYPICAL FOR EACH SECTION OF SWITCHBOARD, PANELBOARDS, ETC.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
