A rated wall assembly penetration designated as System No. W-L-3111 with 1 and 2 hour F ratings and a 0 hour T rating. The assembly consists of a wall substrate, through-penetrating cables, and a firestop sealant system forming a protective barrier.
System No. W-L-3111 F Ratings - 1 and 2 Hr A A SECTION A-A 1 3 T Rating - 0 Hr 2 4
