Lighting control installation details featuring two typical NX switch station models connected via CAT5/6 cable. The first assembly is an NX Switch Station typical model NXSW-ORLO with ON, up/down arrows, and OFF buttons, requiring verification of quantity and type. The second assembly is an NX Switch Station typical model NXSW-6 with six blank buttons included as required. Both devices feature mounting yokes with screw slots and service pin and power indicators.
SVC PIN SVC PWR CAT5/6 Cable SVC PWR SVC PIN ON OFF NX Switch Station Typical Model : NXSW-ORLO VERIFY QTY/TYPE NX Switch Station Typical Model : NXSW-6 (As required)
