Transformer Equipment Nameplate Layout and Sizing Detail

About this detail

This drawing outlines the fabrication and layout details for an electrical equipment nameplate associated with a transformer fed from medium voltage source MVB at 12.47kV, 3-phase, 3-wire, feeding USB-1.1B at 480/277V, 3-phase, 4-wire with a capacity of 2800kVA. The nameplate uses green Gravopoly material number 17442 with bold style text centered horizontally. The layout specifies a minimum height of four and five-eighths inches and a variable width with a five-inch minimum, accompanied by detailed line-by-line vertical spacing dimensions ranging from one-quarter inch to one inch. Fastening is specified using rivets rather than double-stick tape at all locations.
