Two number ten sheet metal screws secure each side to the backing channel designated as 8/S-600. Non-metallic bushings and insulators provide thermal or electrical separation across the bolted connection using stainless steel fasteners.
(2)-#10 SMS EA SIDE INSULATOR (TYP.) BUSHING (TYP.) NON-METALLIC NON-METALLIC (2)-#10 SMS EA SIDE STAINLESS STEEL FASTENERS BACKING: 8/S-600
