Provide one nPODM 4S wall switch station for each exhaust fan with locations coordinated with mechanical requirements. Program the controls as directed by mechanical disciplines and provide one spare nPODM 4S unit.
LF-11 1 2 3 4 nPODM 4S PROVIDE (1) nPODM 4S FOR EACH EXHAUST FAN. PROVIDE ONE SPARE nPODM 4S. COORDINATE LOCATIONS WITH MECHANICAL. PROGRAM CONTROLS AS DIRECTED BY MECHANICAL. (TYP) S LV 11-S LV 15
