An EST Siga series manual fire alarm pull station installs on a standard one and one half inch deep compatible electrical box. A back plate houses a normal toggle switch and secures to the box with cover release screws. A front housing with a glass rod release lever and a pull in case of fire handle attaches over the back plate.
LIFT RELEASE LEVER GLASS ROD COMPATIBLE ELECTRICAL BOX TOGGLE SWITCH NORMAL PLATE BACK ALARM E PULL IN CASE OF FIRE COVER RELEASE SCREW FIRE
