Plug load control complies with California Energy Code Section 130.5 (D) requiring permanent marking of the controlled receptacle. Duplexes requiring controlled outlets within six feet feature a split-wired configuration with one uncontrolled and one controlled receptacle. Control is managed via a local occupancy sensor as indicated on the electrical plans.
NOTES: 1. PLUG LOAD CONTROL PER CALIFORNIA ENERGY CODE SECTION 130.5 (D). PROVIDE PERMANENT MARKING OF CONTROLLED RECEPTACLE. 2. FOR ALL DUPLEXES REQUIRING CONTROLLED RECEPTACLES WITHIN 6ft PROVIDE (1) SPLIT-WIRED DUPLEX RECEPTACLE, WITH (1) UNCONTROLLED AND (1) CONTROLLED RECEPTACLE. 3. CONTROL SHALL BE VIA LOCAL OCCUPANCY SENSOR AS SHOWN ON PLANS. CONTROLLED RECEPTACLE
