Conduits are directly buried with size and quantity as indicated and required, placed beneath backfill conforming to civil drawings and specifications. Red warning tape is positioned a minimum of three feet below the finished grade. Dimensional clearances for the installation include three inches and four inches.
SIZE & QUANTITY OF CONDUITS AS INDICATED AND/OR REQUIRED. CONDUITS DIRECTLY BURIED. BACKFILL PER CIVIL DRAWINGS AND SPECIFICATIONS. FINISHED GRADE PROVIDE RED WARNING TAPE 3" 4" 3" 3" 3" AS REQUIRED 3'-0"MIN.
