An occupancy sensor and a low voltage dimming switch connect to control units using typical Ethernet cables. The devices utilize modular plug connections for communication and power distribution.
LOW VOLTAGE DIMMING SWITCH OCCUPANCY SENSOR ETHERNET CABLE, TYP.
