A twenty-four inch diameter concrete pole base extends nine feet into the ground with a finished grade line marking thirty-six inches from the top and eighteen inches of burial cover to the first conduit sweep. The lighting pole mounts onto three-quarter inch diameter anchor bolts, typical of four, encircled by three places of number four tie bars. Grout fills all around the handhole and base cover, while one inch diameter rigid conduits supply the light and CCTV fiber media converter. The top edge features a two inch forty-five degree chamfer.
9'-0" DIA. ANCHOR BOLTS (TYP. OF 4) (TYP. 3 PLACES) #4 TIE BAR AROUND BOLTS " 4/3 24" DIA. 2" 45 CHAMFER LIGHTING POLE-SEE SCHEDULE ON THIS SHEET GROUT ALL AROUND HANDHOLE 1" DIA. CONDUIT 1" DIA. RIGID CONDUIT FOR LIGHT BUSHING FINISHED GRADE 36" 18" COVER 6" PROVIDE 1" DIA. RIGID CONDUIT FOR CCTV FIBER MEDIA CONVERTER. SEE SITE PLAN E-101 CONSTRUCTION NOTE #22 FOR WHERE THE FIBER MEDIA CONVERTER CIRCUIT CONDUIT IS REQUIRED POLE BASE GENERAL NOTES 1. LOCATE CONCRETE POLE BASE 12" BEHIND FROM THE CURBS AND BACK OF THE SIDEWALKS. COORDINATE EXACT LOCATION WITH LANDSCAPE PRIOR TO ROUGH-IN.
