This diagram details the internal arrangement and component layout of an electrical lighting control panel enclosure. The assembly includes a top-mounted LED driver, circuit boards labeled A and C, terminal blocks for low-voltage and line-voltage connections, and network ports. Fasteners secure the printed circuit boards and components to the interior backplate.
