A 4-inch square junction box is mounted directly to the structure above in an open ceiling condition. Two Category 6A cables terminate to a data jack faceplate. A 1-inch conduit, or J-hooks above accessible lay-in ceilings, routes cabling to the cable tray. An owner-provided wireless access point attaches below.
4" SQUARE BOX MOUNTED TO STRUCTURE. PROVIDE (2) CAT 6A TERMINATED TO DATA JACK FACEPLATE 1" CONDUIT (OR J-HOOKS ABOVE ACCESSIBLE LAY-IN CEILINGS ONLY) TO CABLE TRAY WIRELESS ACCESS POINT (WAP) PROVIDED BY OWNER STRUCTURE ABOVE (CEILING OPEN TO STRUCTURE)
