Electrical · E-B3GGE

Motor Control Center Single Line Diagram

Elements

About this detail

An electrical single-line diagram details motor control center feeds, main breakers, and connected equipment circuits for industrial processing machinery. Power feeds originate from the main breaker through specified conductor runs, including three #12 wires with a #12 ground in three-quarter inch conduit for individual equipment drops. Labeled equipment connections include furnace spray pumps, ash conveyors, rotary air locks, scrubbers, and exhaust fans complete with individual tag numbers. A main ground connection utilizing a four-zero bare copper conductor ties into the system grounding network.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
