E-AZGRQ — Site Lighting Trenching Detail

Electrical · E-AZGRQ

Site Lighting Trenching Detail

About this detail

This trench detail for site lighting shows an electrical conduit installed in a trench with a minimum depth of twenty-four inches and a width of twelve inches. The conduit is set within a ten-inch bedding layer at the trench bottom, overlaid by backfill up to the finished grade. Tagged components include marking tape, backfill material, bedding, conduit, native soil, trench bottom, finished grade, and trench surface.

24" MIN 12" 10" T7 T1 T6 T3 T4 T2 T5 T8

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
