An exterior lighting fixture is mounted atop a cast junction box set flush into a twelve-inch by twelve-inch by twelve-inch concrete pad. A three-quarter-inch PVC conduit feeds into the bottom of the junction box and routes underground. A six-inch clearance dimension is maintained above the concrete pad to the fixture head.
CAST JUNCTION BOX 12" X 12" X 12" CONC. PAD 3/4" PVC CONDUIT 6"
