A pipe is secured to a Unistrut P2493 bracket using a through-bolt or weld to prevent rolling and sliding. Power and low voltage boxes are positioned six inches above the bracket and mounted adjacent to a vertical surface. The ceiling is shown for reference above the electrical boxes.
6" BOXES FOR POWER AND LV PIPE TO BE SECURED TO BRACKET TO PREVENT ROLLING AND SLIDING. TYP. THROUGH-BOLT(SHOWN) OR WELDING. BOXES FOR POWER AND LV CEILING SHOWN FOR REFERENCE BRACKET: UNISTRUT P2493 TYP. 8"
