This electrical one-line diagram details the PLC-CFG2 I/O drop 2 configuration for the cake pump 2 control panel, designated as PNL-73186. The system receives 120VAC power supplies, including a secondary source and an uninterruptible power supply source. Downstream connections feed the centrifuge 2 control panel PNL-74028, the cake pump 2 HPU control panel PNL-72421, and maintenance box PNL-73188 located in the SCB second floor area F.
CAKE PUMP 2 CONTROL PANEL (PNL-73186) PLC-CFG2 I/O DROP 2 ONE-LINE DIAGRAM SCB 2ND FLOOR - AREA F MAINT BOX PNL-73188 CAKE PUMP 2 HPU CONTROL PANEL PNL-72421 CENTRIFUGE 2 CONTROL PANEL PNL-74028 120VAC POWER SUPPLY (UPS) 120VAC POWER SUPPLY SOURCE 2 120VAC POWER SUPPLY
