E-A7BVF — Description

Electrical · E-A7BVF

Description

About this detail

This diagram details the terminal designations and wiring connections for the SIGA-SB standard base. Terminal one is not used, terminal two connects to data in and out positive, terminal three is not used, terminal four connects to data in negative, terminals five and six are not used, and terminal seven connects to data out negative.

TERM 1 4 3 2 5 7 6 DESCRIPTION DATA IN (-) DATA OUT (-) NOT USED NOT USED NOT USED NOT USED DATA IN/OUT (+) DATA IN (-) DATA IN (+) DATA OUT (-) DATA OUT (+)

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
