This electrical demolition diagram outlines the removal or modification of connections linking an existing cogeneration generator rated at 4.375 MVA and 12.47 kV to existing emergency switchgear within the cogeneration motor control center room. The schematic details the partial main breaker one-line configuration associated with circuit identifier 73DAB2.
I I «" I I I <D 4.375 MVA 12.47KV G COGENERATION GENERATOR EXISTING SWITCHGEAR EM EXISTING PARTIAL MAIN BREAKER ONE-LINE 73DAB2 DEMOLITION (COGEN MCC ROOM) NO SCALE
