An electrical one-line diagram continuation feeds to switchboard MSB2076BP referencing sheet E00-014. The main feeder features an eight hundred amp frame with eight hundred amp trip three pole circuit breaker at position nine. A secondary spare circuit features a four hundred amp frame with three hundred amp trip three pole circuit breaker at position ten.
800AF 800AT 3P 9 400AF 300AT 3P 10 SPARE 016A TO "MSB2076BP" REFER TO SHEET E00-014 FOR CONTINUATION PH2 AA
