Electrical · E-9A6PS

Siga-Cr

About this detail

This diagram details the fail-safe wiring connections for three SIGA-CR control relays managing elevator recall, elevator alternate recall, and elevator shunt trip functions. Each relay utilizes normally closed contacts, common, and normally open connections routed to designated interface terminals. Data out positive and negative lines tie into the lower control terminals for system communication. Notes instruct utilizing normally closed contacts where possible to achieve fail-safe wiring.
