A manual temporary generator transfer device and connection cabinet is provided for generator maintenance operations in accordance with the 2017 electrical code. The assembly integrates temporary generator cam locks to facilitate safe connection of external power sources. Wiring provisions tie directly into the enclosure to support emergency power transfer.
MANUAL TEMP GENERATOR TRANSFER DEVICE AND CONNECTION CABINET FOR GENERATOR MAINTENANCE (NEW PER 2017 CODE) TEMP GEN CAM LOCKS
