Electrical · E-8Z7KP

Centrifuge 4 Power Panel One-Line Diagram

About this detail

Power distribution feeds Centrifuge 4 Power Panel CPP-4 from Motor Control Center feeder MCC73T4-39. The panel supplies power to the bowl drive, scroll drive, lube oil pump, and associated motor starter and temperature switch devices via designated conduit and conductor sizes ranging from number fourteen to five-hundred kilomil. Additional connections route power to Centrifuge 4 Control Panel PNL-74049 across multiple circuits.
